1 Ton Rolon Unit

Select a colour to Request A Quote

1 Ton Rolon Unit

This unit was designed to replace the cable winch cage loader. By means of a simple retrofit to your existing 8 cubic metre cage bins, you can now load a bin onto the vehicle in less than 20 seconds and the cage is secured without any tie downs. The benefits of this unit is that it is much safer to work with as well as ease of use. This coupled with the fact that offloading product becomes less dangerous due to the cage being rigid on the truck at all times during the loading and off-loading process. Designed and manufactured locally spare parts are readily available.

OPTION 1 Ton Rolon Unit
Height From Ground 2800mm
Width 2140mm
Required CA Dimension 1900mm
Tare Weight 400kg
OPTION 1 Ton Rolon Unit
Sub Frame 3mm Supraform 700
Hook Frame 4mm Supraform 700
Lift Hook 25mm Roqtuf Plate
OPTION 1 Ton Rolon Unit
Hydraulic Pump Rating 25 MPa
PTO Required Torque 250 Nm
Required Flow Rate 16 L/min
Pump RPM 1000
Main Relief Pressure 20 MPa
Hydraulic Tank Capacity 20L
  • Fire Extinguisher
  • Fire Extinguisher Holder
  • Chock Blocks
